Product Parameters:
Model: YTQM-0.4L
Injection size (different materials): ≤ 10mm, (0.4L for other materials ≤ 3mm)
Sample size:<100nm
Minimum processing capacity: 50ml/tank
Maximum processing capacity: 4x100ml
Main disk speed: 50-400r/min
Ball mill speed: 100-800r/min
Transmission ratio: 1: -2
Forward and reverse operation: Yes
Dangerous emergency stop: Yes
Grinding room lighting: none
Ball milling carrier materials: stainless steel (304/316), tungsten carbide (WC), nylon (MC), polyurethane (PU), polytetrafluoroethylene (PTFE), polypropylene tank (PP), nylon (PA), zirconia tank (ZRO), corundum tank (ALO), agate ball milling tank (SI0), vacuum ball milling tank, polyurethane vacuum ball milling tank, corundum vacuum ball milling tank, agate vacuum ball milling tank, etc. are optional
Carrier volume: 50ml-100ml
Material of ball milling medium: stainless steel (304/316), tungsten carbide ball (wc), agate ball (SI0), zirconia ball (ZRO), corundum ball (ALO), polytetrafluoroethylene ball (PTFE), polypropylene ball (PP), nylon ball (PA), polyurethane ball (PU) optional
Medium diameter: 3/5/10/15/20mm
Medium quality: 100-400g
Grinding method: dry grinding/wet grinding
Low temperature cooling treatment: Yes (additional)
Inert gas protection treatment: Yes
Size (length x width x height mm): 530x300x340
Net weight: 29KG
Standard: CE
- Product Details
- Product manual
Yetuo YTQM-0.4L planetary ball mill
Model: YTQM-0.4L
Product Overview:
The planetary ball mill adopts AC motor frequency conversion program control and is equipped with four ball milling tanks on a turntable. When the turntable rotates, the central axis of the ball milling tank moves in a planetary motion. The grinding balls in the tank grind and mix samples at high speed, which can be used for pharmaceuticals, biological samples, inorganic substances, minerals, organic substances, as well as paper, chips, polymers, etc.
Product features of Yetuo YTQM-0.4L planetary ball mill
● Efficient and rapid grinding
Optimizing the grinding mechanism significantly improves processing speed and flux, significantly shortens the experimental cycle, and significantly improves efficiency compared to conventional equipment;
Intelligent and precise regulation
The stepless speed regulation function achieves precise speed control, smooth operation with low vibration, and adapts to the grinding needs of different hardness samples;
● Long lasting and stable operation
Specially designed for long-term continuous sample preparation, with a durable structure that ensures uninterrupted and efficient operation, meeting the needs of large-scale sample processing;
Visual intelligent operation
The interactive interface displays the operating power in real-time, and the crushing time can be set between 1-99 minutes. The parameters are flexible and adjustable, and the entire experimental process is controllable;
